DS-2CE16D8T-ITE Specification

Camera

Image Sensor

2MP CMOS Image Sensor

Signal System

PAL/NTSC

Effective Pixels

1920(H)*1080(V)

Shutter Time

1/25(1/30) s to 1/50,000 s

Lens Mount

M12

Adjustment Range

Pan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360°

Day& Night

IR cut filter

Wide Dynamic Range

120dB

Video Frame Rate

1080p@25fps/1080p@30fps

HD Video Output

1 Analog HD output

Synchronization

Internal Synchronization

Up the Coax

Support

Menu

Auto White Balance

Auto/MWB

BLC

Support

AGC

Support

HLC

Support

Language

English

General

Operating Conditions

-40 °C - 60 °C (-40 °F - 140 °F)

Humidity 90% or less (non-condensing)

Power Supply

12 VDC±25%/PoC.af

Weather Proof

IP67

IR Range

Up to 30m

Communication

Up the coax

Protocol: HIKVISION-C (Coaxitron)

Dimension

58 mm × 61 mm × 163 mm (2.28" × 2.40" × 6.42")
