| Feature | Specification |
|---|---|
| CPU | Quad core 1.4 GHz Hardware Acceleration Engine Layer 4 / Layer 7 |
| Memory | 512 MB DDR4 |
| Antenna Type | 4×4 MIMO high-performance internal antenna (5 GHz), 2×2 MIMO high-performance internal antenna (2.4 GHz) |
| LAN Port | 2.5GbE (RJ-45) x 1, Gigabit (RJ-45) x 3 |
| WAN Port | Gigabit (RJ-45) x 1, 2.5 GbE (RJ-45) x 1 (Dual WAN) |
| External Ports | USB 3.2 Gen 1 x 1 (5V, 0.9A power output) |
| Wireless Standard | IEEE 802.11ax, IEEE 802.11a/b/g/n/ac/ax |
| Data Rate | 2.4GHz: 600Mbps, 5GHz: 2400Mbps |
| Wi-Fi Features | Simultaneous dual-band Wi-Fi |
| Wi-Fi Encryption | WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, Wi-Fi Enhanced Open (OWE) |
| Button and Switch | WPS, Power, Reset, Wi-Fi On/Off |
| Size | 233 mm x 194 mm x 66 mm |
| Weight | 1.35 kg |
| Operating Temperature | 5°C to 40°C (40°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification | FCC, UKCA, CE, BSMI, VCCI, RCM, KC, iDA, TELEC, JATE, IC |
| Wi-Fi Certification | CE, UKCA, FCC, NCC, RCM, iDA, TELEC, KC, IC |
| Warranty | 2 Years |
| AC Input Power | 100 V to 240 V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 10.80 W (Access), 7.94 W (Idle) |
| Environment | RoHS Compliant |
| Packaging Content | Main Unit, AC Power Adapter, RJ-45 LAN Cable, Quick Installation Guide |
