CAMERA Image Sensor 1/2.7” Progressive Scan CMOS Aperture 4 mm: F2.2
2.8 mm: F2.2Lens 4 mm / 2.8 mm Lens Mount M12 Minimum Illumination Color: 0.1 Lux@F2.0; 0 Lux with IR Day/Night Mechanism IR Cut Filter Digital Noise Reduction 3D DNR WDR DWDR IR Working Distance 30m Viewing Angle (4 mm) horizontal FOV: 82.5°, vertical FOV: 44.9°, diagonal FOV: 99.3°
(2.8 mm) horizontal FOV: 97.8°, vertical FOV: 52.9°, diagonal FOV: 117.9°Pan/Tilt Range Pan: 0° to 360°, Tilt: 0° to 85°, Rotate: 0° to 360° NETWORK Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS API ONVIF Simultaneous Live View 4 Main Streams & 3 Sub-Streams,
or 3 Main Streams & 5 Sub-StreamsSecurity Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication INTERFACES Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port Button - Video Output - GENERAL Weight 195 g Package Contents VIGI Network Camera
Quick Start Guide
Screws and Anchors
Mounting TemplateDimensions( H X W X D ) 123 × 123 × 83 mm Material Plastic General Features Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening Power Requirements 12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3af/at, class 0)Power Supply 12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3af/at, class 0)Power Consumption 12V DC: Max 2.4W
PoE: Max 3WCertifications CE, FCC, RCM, BSMI, VCCI, RoHS VIDEO/IMAGE Video Compression Main stream: H.265/H.264
Sub-Stream: H.265/H.264Frame Rate & Resolutions Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720, 704x576, 640x480, 352x288, 320x240Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software Image Enhancement BLC/3D DNR/Prevent Overexposure to Infrared Light Video Bit Rate 64 Kbps to 6 Mbps SMART FEATURE-SET Smart Event Area Intrusion Detection, Line-Crossing Detection Basic Event Motion Detection, Video Tampering Detection, Exception ( illegal login) Linkage Method Trigger Notification: ONVIF, HTTPS Region of Interest 1 Region
-
